Vertical Segment
Desktop
Processor Number
G3240
Lithography
22 nm
CPU Specifications
# of Cores
2
# of Threads
2
Processor Base Frequency
3.10 GHz
Cache
3 MB Intel® Smart Cache
Bus Speed
5 GT/s
TDP
53 W
Memory Specifications
Max Memory Size (dependent on memory type)
32 GB
Memory Types
DDR3-1333, DDR3L-1333 @ 1.5V
Max # of Memory Channels
2
Max Memory Bandwidth
21.3 GB/s
ECC Memory Supported ‡
Yes
Processor Graphics
Processor Graphics ‡
Intel® HD Graphics for 4th Generation Intel® Processors
Graphics Base Frequency
350 MHz
Graphics Max Dynamic Frequency
1.10 GHz
Graphics Video Max Memory
1.7 GB
Graphics Output
eDP/DP/HDMI/DVI/VGA
Max Resolution (HDMI)‡
1920x1080@60Hz
Max Resolution (DP)‡
2560x1600@60Hz
Max Resolution (eDP - Integrated Flat Panel)‡
2560x1600@60Hz
Max Resolution (VGA)‡
1920x1200@60Hz
DirectX* Support
11.1/12
OpenGL* Support
4.3
Intel® Quick Sync Video
Yes
Intel® Clear Video HD Technology
Yes
# of Displays Supported ‡
3
Expansion Options
Scalability
1S Only
PCI Express Revision
Up to 3.0
PCI Express Configurations ‡
Up to 1x16, 2x8, 1x8+2x4
Max # of PCI Express Lanes
16
Package Specifications
Sockets Supported
FCLGA1150
Max CPU Configuration
1
Thermal Solution Specification
PCG 2013C
TCASE
72°C
Package Size
37.5mm x 37.5mm
Advanced Technologies
Intel® Optane™ Memory Supported ‡
No
Intel® Turbo Boost Technology ‡
No
Intel vPro® Platform Eligibility ‡
No
Intel® Hyper-Threading Technology ‡
No
Intel® Virtualization Technology (VT-x) ‡
Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡
No
Intel® VT-x with Extended Page Tables (EPT) ‡
Yes
Intel® Transactional Synchronization Extensions
No
Intel® 64 ‡
Yes
Instruction Set
64-bit
Instruction Set Extensions
Intel® SSE4.1, Intel® SSE4.2
Idle States
Yes
Enhanced Intel SpeedStep® Technology
Yes
